Intra Corporeal Electro Pneumatic Lithotripsy System
Features
-
Clinically proven technology.
-
Conveniently connects directly to the hospital's compressed air system or oxygen cylinder.
-
Suction adaptor for PCNL keeps the vision clear, sucks out the debris.
-
Frequency from 1 to 20.
-
To adjust each frequency output there is one more function namely BOOST.
-
BOOST ranges from 1 to 21
-
With adjusting all these functions we will get a perfect stroke on the stone and the lateral movement of probe is minimised.
-
The implementation of modern pressure sensor makes it stop if pressure goes down below 1.5 bar. Pressure goes upto 7.0 bar.
Safe
-
No significant heat is generated on either the probes or the control box, hence it does not cause any kind of thermal injury to the patient.
-
PARIBLAST is safe from electrical hazard for both patient and user, as it does not use electrical power to camy the kinetic shock wave impulses to the probe.
-
PARIBLAST has an input voltage of 110 to 240 to avoid damage due to voltage fluctuations.
Effective
-
PARIBLAST is effective to all kind of renal, urethral and bladder stones.
-
Kinetic energy transmission by direct contact to the probes provides maximum efficiency for the fragmentation of the stones.
Technical Specifications
| Input voltage | Classification | Input Pressure | Control unit | Hand Piece |
|---|---|---|---|---|
| 90 to 240 VAC | EN 60601-1 Class ll b Applied Part type BF IP 40 92 / 42 / EEC | 0 to 7 bar | Weight - 2.5 kg Height - 95 mm Length - 250 mm Width - 240mm | Weight - 300 gm Length - 170 mm Diameter - 17 mm |
